ADJ UV Par 100IP - IP65, 100W UV C.O.B Par

The ADJ UV Par 100IP is a high-output UV COB LED par fixture, designed for robust outdoor and indoor applications. This IP65-rated fixture combines powerful ultraviolet lighting with reliable performance for various professional lighting setups.

Key Features

1. Powerful UV Output

• 100W COB UV LED: Delivers intense and uniform ultraviolet lighting, ideal for creating striking blacklight effects.
• Wide Coverage: Emits a wide-angle beam for expansive area coverage.

2. IP65 Weatherproof Rating

• Outdoor-Ready: Dust-tight and water-resistant, ensuring reliable performance in outdoor environments.
• Durable Construction: Built to withstand extreme weather conditions and rugged use.

3. Versatile Design

• Compact and Lightweight: Easy to install and transport for mobile applications.
• Multiple Mounting Options: Includes dual yoke brackets for floor-standing or truss-mounted configurations.

4. Control and Connectivity

• DMX Control: Flexible programming with multiple DMX channel modes.
• Standalone Operation: Includes manual control options for quick setup.

5. Energy Efficient

• Low Power Consumption: Optimized for prolonged use with minimal energy requirements.
• Long LED Life: Ensures cost-effective operation and reduced maintenance.

Applications

• Concerts and Festivals: Adds dramatic UV effects to enhance visual aesthetics.
• Theme Parks and Attractions: Ideal for immersive environments and decorative lighting.
• Clubs and Nightlife: Creates vibrant atmospheres with dynamic blacklight effects.
• Architectural Lighting: Highlights structures and features with bold UV illumination.
• Theatrical Productions: Perfect for special effects and scene highlights.

Light Source:

• 1x 100W C.O.B. Ultraviolet LED
• 120° Beam Angle
• Wavelength: 390-399nm
• 30,000 Hour Average LED Life

Features:

• Aria X2 Wireless Management System
• Control Protocol: DMX & RDM
• DMX Modes: 4 (1, 2, 3, & 6 Channel Modes)
• Dim Modes: 6 Presets (Standard, Stage, TV, Architectural, Theatre & Stage 2)
• Dim Curves: 4 Presets (Square, Linear, Inv. Curve & S-Curve)
• Dim Speed control (0.1~10 Seconds)
• Dimming: 0 - 100%
• Linear, Pulse and Random Strobe control
• Adjustable LED Refresh Rates (900~25k Hz)
• With Wired Digital Communication Network
• Display: OLED display with 4-button touch menu

Connections:

• Data Input: IP65 rated 5pin DMX In/Out
• Power Input: IP65 power locking In/Out (with protective rubber caps)

Electrical:

• 100-240V 50Hz/60Hz (Auto Sensing)
• Max Power Consumption: ?W

Physical:

• Outdoor Rated, IP65: protects from dust, sand, moisture, liquid. 6 (Protection against Dust); 5 (Protection against Water)
• Please note: you must use IP65 data and power cables in order for this fixture to be IP65 outdoor rated.
• Safety Cable Loop
• Scissor yoke with Omega bracket receivers (Omega Bracket sold separately)

Dimensions / Weight:

• Length: 14.4” (367mm)
• Width: 12.4” (316mm)
• Height: 8.7” (111mm)
• Weight: 14.11lbs. (6.4kg)

What’s Included:

• 1x IP65, 6' locking power cable (1.83m)

Approvals:

• cETLus (Control # 4010765)
• CE Compliant
• FCC Compliant
