Crown CDI1000 275W 2-Channel Solid-State Power Amplifier



-2 ohm dual (per channel): 700W -4 ohm dual (per channel): 500W -8 ohm dual (per channel): 275W -4 ohm bridge-mono: 1,400W -70V dual (per channel): 500W -140V bridge-mono: 1,000W

Crown CDi 1000 275W 2-Channel Solid-State Power Amplifier Crown CDi Series amplifiers are professional tools designed and built for installed sound applications. The series includes four models which are identical except for output power: CDi 1000, CDi 2000, CDi 4000, and CDi 6000. All are rugged and lightweight, and offer unmatched value in their class. Extremely versatile; rated for 2-, 4-, 8-ohm loads and 70V and 140V outputs. Switch-mode universal power supply. Intuitive front-panel LCD screen for quick, easy configuration. Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting. Up to 20 user defined DSP presets are available. Power 2 ohm dual (per channel): 700W 4 ohm dual (per channel): 500W 8 ohm dual (per channel): 275W 4 ohm bridge-mono: 1,400W 70V dual (per channel): 500W 140V bridge-mono: 1,000W

More Information
Freeshipping Free Shipping
UPC (Universal Product Code) 00871015002125
MPN (manufacturer part number) CDI1000
Condition New
Features Accurate, uncolored sound with very low distortion for the best in music and voice reproduction Extremely versatile; rated for 2, 4, 8 ohm loads and 70V/100V and 140V outputs Advanced protection circuitry guards against: shorted outputs, open circuits, DC, mismatched loads, general overheating, high-frequency overloads and internal faults Intuitive front-panel LCD screen for quick, easy configuration Switch-mode universal power supply Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting 2U rack space Barrier strip outputs for low-Z or 70V/100V/140V loads, removable Phoenix-style inputs Three-year, no-fault, fully transferrable warranty completely protects your investment and guarantees its specifications
Specs Frequency Response 20Hz - 20kHz (@ 1W into 4 Ohms) Sensitivity 1.4V @ 8 Ohms Signal to Noise Ratio 100dB Voltage Gain 30.5dB (@ 1kHz, 8 Ohm Rate Output) Load Impedance Rated for 2-8 Ohms in Stereo Mode Rated for 4-16 Ohms in Bridge-Mono Mode Input Impedance 20 kOhms (Nominal) Output Power 700W @ 2 Ohm Dual (Per Channel) 500W @ 4 Ohm Dual (Per Channel) 275W @ 8 Ohm Dual (Per Channel) 1400W @ 4 Ohm Bridge-Mono 500W @ 70V Dual (Per Channel) 1000W @ 140V Bridge-Mono Damping Factor Better than 500 from 20 to 400Hz Crosstalk >70dB Below Rated Power, 20Hz to 1kHz Max Input Signal +22dBu Typical Inputs 2 x 3-Pin Removable Phoenix-Type Outputs 4-Position Barrier Strip with Connectors for Dual Loudspeakers or Bridge-Mono Loudspeaker Power 100V, 120V-240V, 50/60 Hz Dimensions (WxHxD) 19 x 3.5 x 12.25" (483 x 89 x 311mm) Weight 19 lb (8.6 kg)
Producut Video No
