Dynacord MXE5-64 - 64x64 Matrix Mix Engine
- Open architecture DSP matrix for high performance audio applications
- 12 mic/line inputs, 8 line outputs, 8 configurable GPIOs
- 64 x 64 Dante channels
- TaskEngine for sophisticated system control and integration
- Integrated into SONICUE Sound System Software
Have a Question? Ask an Account Manager
Call us: (516) 597-5450
Or: Conatct Us
The Dynacord MXE5-64 is a professional-grade 64x64 matrix mix engine designed for high-performance audio processing in live and installed sound applications. It is part of Dynacord's portfolio of advanced audio system solutions and integrates cutting-edge technology for seamless control, routing, and audio processing.
Key Features:
-
Matrix Mixing Capability:
- Offers 64 input and 64 output channels for flexible routing and mixing.
- Supports extensive DSP features such as EQ, compression, and delay.
-
High Audio Quality:
- Delivers studio-grade sound with low latency and high dynamic range.
- Supports 96 kHz sampling rate for superior audio fidelity.
-
Integrated DSP:
- Built-in DSP allows for advanced signal processing without requiring external processors.
- Includes room EQ, feedback suppression, auto-mixing, and more.
-
Networked Audio Support:
- Supports Dante, AES67, and OMNEO protocols for audio networking.
- Facilitates seamless integration into modern AV systems.
-
Control and Monitoring:
- Compatible with Dynacord’s SONICUE software for intuitive system control and configuration.
- Provides real-time monitoring and status updates.
-
Scalability:
- Ideal for medium to large venues, such as theaters, conference centers, and houses of worship.
- Modular design allows for expansion as system requirements grow.
-
Redundancy and Reliability:
- Supports redundant network setups for fail-safe operation.
- Designed for 24/7 operation with robust hardware components.
-
Integration Capabilities:
- Easily integrates with third-party control systems like Crestron and AMX.
- Offers GPIO and control ports for external device interaction.
The Dynacord MXE5-64 is an excellent choice for audio professionals looking for a powerful, versatile, and reliable solution for complex audio routing and processing needs
Specifications
| DSP Matrix Mix Engine | Open architecture DSP, sound system manager, system control and supervision |
| Matrix Size | Flexible with 3860 cross-points, 256 signal paths |
| Dante audio (48/96 kHz) | 64 x 64 channels (64 Flows) |
| Analog Inputs | 12 mic / line w. 48V phantom power |
| Analog Outputs | 8 line |
| Control ports | 8 GPIO (digital in/out, analog in) |
| Signal to Noise Ratio (A-weighted) | > 118 dB |
| THD+N | < 0.002 % |
| Sampling rate | 96 kHz / 48 kHz |
| Latency (analog in/out, 96/48 kHz) | < 0.22 ms / 0.45 ms |
| Signal Processing | 32/40-bit floating point |
| Max. input/output level | + 22 dBu |
| DSP blocks | EQs, x-over, FIR drive, compressor, PA & RMS limiter, noise gate, ducker, automatic gain control, ambient noise compensation, mix-matrix, router, auto mixer, delay, generators, detectors, VU meters, polarity, level, mute |
| TaskEngine (system logic) | Analog, logic and text operations, scheduler, scene handling, OCA & HTTP protocol |
| Safety / Redundancy | Int. supervision, system monitoring, watchdog, fault output, audio redundancy supported |
| Dimensions (w x h x d) | 483 x 43.5 x 471 mm (19”, 1RU) |
| Weight | 6.0 kg (13.2 lbs) |
| Condition | New |
|---|---|
| MPN (manufacturer part number) | MXE5-64 |
