QSC RMX850a 200W RMX Series Power Amplifier

Special Price $399.00 Regular Price $465.00

discount



SKU
QSC-RMX850a

• Compact size - up to 2400 watts in 2 rack spaces • Professional quality performance - incorporates road-proven QSC designs • High-current toroidal transformers for greater two-ohm power and low noise • Independent user-defeatable clip limiters reduce distortion
The RMX Series amplifiers give you clean, dynamic power with the legendary QSC sound quality and reliability that pros depend on. The RMX Series deliver unmatched performance at a breakthrough price. And with QSC's free 6 year warranty, the RMX is an even better value. * Muscular Power Plant The power supply is the heart of an amplifier, converting raw AC power from the wall to clean DC for the audio circuitry. The RMX uses a powerful high-current toroidal transformer and ample filter capacitance to ensure generous energy reserves. This makes a critical difference in sound quality, allowing the amp to effortlessly punch out high level transients, even when driving abusive 2 ohm speaker loads. Superior Performance RMX amplifiers deliver true studio-quality sound. A full complementary output circuit using the highest-grade linear output devices delivers ultra-low distortion (<0.05% THD) and a ruler-flat frequency response. SMT (Surface Mount Technology) triples small-signal component density, enabling us to pack up to 2400 watts of power in a chassis only 2 rack spaces and less than 16" deep. And unlike other designs, RMX output devices are direct-mounted to the heat sink for optimum thermal coupling and cooling.
More Information
SKU QSC-RMX850a
Freeshipping Free Shipping
UPC (Universal Product Code) 00684284062765
MPN (manufacturer part number) RMX850a
Discount INSTANT SAVINGS: 10% OFF
Condition New
Features • Compact size - up to 2400 watts in 2 rack spaces • Professional quality performance - incorporates road-proven QSC designs • High-current toroidal transformers for greater two-ohm power and low noise • Independent user-defeatable clip limiters reduce distortion • Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom • Balanced 1/4" (6.3mm) TRS, XLR and barrier strip inputs • Binding post and Neutrik Speakon outputs • Front mounted gain controls for easy access • Signal and Clip LED indicators to monitor performance • Independent DC and thermal overload protection on each channel automatically protects amplifier and speakers • 3-year warranty plus optional 3-year extended service contract
Specs STEREO MODE (Both Channels Driven) 8 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 185 W 200 W 4 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 280 W 300 W 2 ohms EIA 1 kHz, 1% THD 430 W BRIDGE MONO MODE 8 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 530 W 600 W 4 ohms EIA 1 kHz, 1% THD 830 W Distortion (Typical) 20 Hz - 20 kHz: 10 dB below rated power 1.0 kHz and below: full rated power Less than 0.03% THD, 4 and 8 ohms Less than 0.03% THD, 4 and 8 ohms Frequency Response 20 Hz-20 kHz, ±1 dB -3 dB points: 5 Hz - 50 kHz Damping Factor, 1 kHz and below Greater than 300 at 8 ohms Input Impedance 10k ohms unbalanced, 20k ohms balanced Input Clipping 10 Vrms (+22 dB) Cooling Continuously variable-speed fan, rear-to-front air flow Connectors, each channel Input: Active balanced; barrier strip, XLR and 1/4" (6.3mm) TRS tip and XLR (pin 2 positive) Output: touch-proof binding posts and Neutrik® Speakon® Controls Front: AC switch, Ch. 1 and Ch. 2 gain knobs Rear: 10-position DIP switch Indicators Power-On: Green LED Signal: Yellow LED (1 per channel) Clip: Red LED (1 per channel) Amplifier Protection Stable into reactive or mismatched loads Load Protection On/off muting, AC coupling (850, 1450), triac crowbar (1850HD, 2450, on each channel) Power Requirements 100, 120, 230 VAC, 50-60 Hz Dimensions 19" (48.3 cm) rack mounting, 3.5" (8.9 cm) tall (2 RU), 15.9" (40 cm) deep (rack mounting to rear support ears) Weight 35 lbs (15.9 kg) net
Producut Video No
