QSC RMX850a 200W RMX Series Power Amplifier
• Compact size - up to 2400 watts in 2 rack spaces • Professional quality performance - incorporates road-proven QSC designs • High-current toroidal transformers for greater two-ohm power and low noise • Independent user-defeatable clip limiters reduce distortion
MPN (manufacturer part number) | RMX850a |
---|---|
UPC (Universal Product Code) | 00684284062765 |
Condition | New |
Specs | STEREO MODE (Both Channels Driven) 8 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 185 W 200 W 4 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 280 W 300 W 2 ohms EIA 1 kHz, 1% THD 430 W BRIDGE MONO MODE 8 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 530 W 600 W 4 ohms EIA 1 kHz, 1% THD 830 W Distortion (Typical) 20 Hz - 20 kHz: 10 dB below rated power 1.0 kHz and below: full rated power Less than 0.03% THD, 4 and 8 ohms Less than 0.03% THD, 4 and 8 ohms Frequency Response 20 Hz-20 kHz, ±1 dB -3 dB points: 5 Hz - 50 kHz Damping Factor, 1 kHz and below Greater than 300 at 8 ohms Input Impedance 10k ohms unbalanced, 20k ohms balanced Input Clipping 10 Vrms (+22 dB) Cooling Continuously variable-speed fan, rear-to-front air flow Connectors, each channel Input: Active balanced; barrier strip, XLR and 1/4" (6.3mm) TRS tip and XLR (pin 2 positive) Output: touch-proof binding posts and Neutrik® Speakon® Controls Front: AC switch, Ch. 1 and Ch. 2 gain knobs Rear: 10-position DIP switch Indicators Power-On: Green LED Signal: Yellow LED (1 per channel) Clip: Red LED (1 per channel) Amplifier Protection Stable into reactive or mismatched loads Load Protection On/off muting, AC coupling (850, 1450), triac crowbar (1850HD, 2450, on each channel) Power Requirements 100, 120, 230 VAC, 50-60 Hz Dimensions 19" (48.3 cm) rack mounting, 3.5" (8.9 cm) tall (2 RU), 15.9" (40 cm) deep (rack mounting to rear support ears) Weight 35 lbs (15.9 kg) net |
- QSC RMX850a 200W RMX Series Power AmplifierSpecial Price $679.99 Regular Price $724.99
-
-
- Speakerpower SP2-12000 - 2-Channel 6000W/2 Power AmplifierSpecial Price $3,275.00 Regular Price $4,595.00
-
- Total price
The RMX Series amplifiers give you clean, dynamic power with the legendary QSC sound quality and reliability that pros depend on. The RMX Series deliver unmatched performance at a breakthrough price. And with QSC's free 6 year warranty, the RMX is an even better value. *Muscular Power PlantThe power supply is the heart of an amplifier, converting raw AC power from the wall to clean DC for the audio circuitry. The RMX uses a powerful high-current toroidal transformer and ample filter capacitance to ensure generous energy reserves. This makes a critical difference in sound quality, allowing the amp to effortlessly punch out high level transients, even when driving abusive 2 ohm speaker loads.Superior PerformanceRMX amplifiers deliver true studio-quality sound. A full complementary output circuit using the highest-grade linear output devices delivers ultra-low distortion (<0.05% THD) and a ruler-flat frequency response. SMT (Surface Mount Technology) triples small-signal component density, enabling us to pack up to 2400 watts of power in a chassis only 2 rack spaces and less than 16" deep. And unlike other designs, RMX output devices are direct-mounted to the heat sink for optimum thermal coupling and cooling.
MPN (manufacturer part number) | RMX850a |
---|---|
UPC (Universal Product Code) | 00684284062765 |
Condition | New |
Specs | STEREO MODE (Both Channels Driven) 8 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 185 W 200 W 4 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 280 W 300 W 2 ohms EIA 1 kHz, 1% THD 430 W BRIDGE MONO MODE 8 ohms FTC 20 Hz - 20 kHz, 0.1% THD EIA 1 kHz, 0.1% THD 530 W 600 W 4 ohms EIA 1 kHz, 1% THD 830 W Distortion (Typical) 20 Hz - 20 kHz: 10 dB below rated power 1.0 kHz and below: full rated power Less than 0.03% THD, 4 and 8 ohms Less than 0.03% THD, 4 and 8 ohms Frequency Response 20 Hz-20 kHz, ±1 dB -3 dB points: 5 Hz - 50 kHz Damping Factor, 1 kHz and below Greater than 300 at 8 ohms Input Impedance 10k ohms unbalanced, 20k ohms balanced Input Clipping 10 Vrms (+22 dB) Cooling Continuously variable-speed fan, rear-to-front air flow Connectors, each channel Input: Active balanced; barrier strip, XLR and 1/4" (6.3mm) TRS tip and XLR (pin 2 positive) Output: touch-proof binding posts and Neutrik® Speakon® Controls Front: AC switch, Ch. 1 and Ch. 2 gain knobs Rear: 10-position DIP switch Indicators Power-On: Green LED Signal: Yellow LED (1 per channel) Clip: Red LED (1 per channel) Amplifier Protection Stable into reactive or mismatched loads Load Protection On/off muting, AC coupling (850, 1450), triac crowbar (1850HD, 2450, on each channel) Power Requirements 100, 120, 230 VAC, 50-60 Hz Dimensions 19" (48.3 cm) rack mounting, 3.5" (8.9 cm) tall (2 RU), 15.9" (40 cm) deep (rack mounting to rear support ears) Weight 35 lbs (15.9 kg) net |
