RME 12MIC DANTE - 12-Channel Microphone Preamplifier with Dante, ADAT & MADI

SKU
RME-12MIC-D
  • 12 Mic/Line Inputs with 75 dB Gain
  • 4 TRS/XLR Inputs + 8 XLR Inputs
  • Integrated MADI and Dante Connections
  • Remote and Front-Panel Control
Special Price $3,599.00 Regular Price $3,999.00
Account manager

Have a Question? Ask an Account Manager

The RME 12Mic-D features twelve microphone and line level inputs with digital, no-compromise, studio-quality conversion; remote controllable gains; integrated MADI and Dante connectivity; plus a multitude of additional functionality, designed for use in high-end studio recording, live audio, and location sound and music recording.

Connectivity and Features

1 x Phones Output

4 x XLR/TRS Mic/Inst/Line

8 x XLR Mic/Line

1 x Redundant power supplies

1 x Word Clock I/O

1 x MADI I/O coaxial

3 x ADAT Out

1 x MADI Optical SFP (optional)

2 x Gigabit Ethernet (802.3 compliant)

USB for firmware & remote control

Designed for the Next Decade - RME’s preamps for Audio Networks

The RME 12Mic-D features twelve microphone and line level inputs with digital, no-compromise, studio-quality conversion; remote controllable gains; integrated MADI and Dante connectivity; plus a multitude of additional functionality, designed to make it the perfect companion for any professional recording setup. The 12Mic-D is sonically identical to the already existing 12Mic (with 128 AVB channels) and complements the M-Series lineup of professional network audio solutions.

SPECS



Inputs

XLR In 1-12:

  • Input: XLR, electronically balanced
  • Input impedance: 3.4 kOhm
  • Gain range: 75 dB, 1 dB steps
  • Resolution AD: 24 bit
  • Frequency response @ 44.1 kHz, -0.1 dB: 8 Hz – 20.8 kHz
  • Frequency response @ 96 kHz, -0.5 dB: 4 Hz – 29.2
  • Frequency response @ 192 kHz, -1 dB: 3 Hz – 43.7
  • THD @ 30 dB gain: < -110 dB, < 0.00032 %
  • THD+N @ 30 dB gain: < -104 dB, < 0.00063 %
  • Channel separation: > 110 dB
  • Signal to Noise ratio (SNR): > 117 dB RMS unweighted, > 120 dB(A)
  • Equivalent Input Noise (EIN), 30 dB Gain: 123 dB RMS unweighted, 125.5 dB(A) @ 150 Ohm
  • Maximum input level, Gain 0 dB: +18 dBu
  • Maximum input level, Gain 75 dB: -57 dBu



TRS In 1-4:
As above, but:

  • Signal to Noise ratio (SNR): 115 dB RMS unweighted, 118 dBA
  • TRS jack, balanced
  • Gain range: 42 dB, 1 dB steps
  • Maximum input level, Gain 8 dB: +20 dBu
  • Maximum input level, Gain 50 dB: -22 dBu
  • Switchable high impedance (unbalanced TS): 1 MOhm



DANTE:

  • 2 x RJ45 for Dante network connectivity (up to 64 channels)



MADI:

  • Coaxial via BNC, 75 Ohm, according to AES10-1991
  • Optical via optional SFP module
  • 62.5/125 and 50/125 compatible
  • Accepts 56 channel and 64 channel mode, plus 96k Frame
  • Single Speed: up to 64 channels 24 bit 48 kHz
  • Double Speed: up to 32 channels 24 bit 96 kHz
  • Quad Speed: up to 16 channels 24 bit 192 kHz



Word Clock:

  • 75 ohm Word Clock BNC connectivity
  • Support 44.1kHz - 192kHz
  • Support full or single speed operation
  • Intelligent Clock Control switches clock source seamlessly



ADAT:

  • 3 x TOSLINK
  • Quad Speed (S/MUX4): 1 x 2 channels 24 bit 192 kHz



Outputs

Phones 1/2:

  • Resolution: 24 Bit
  • Noise (DR): 115 dB RMS unweighted, 118 dBA
  • Frequency response @ 44.1 kHz, -0.5 dB: 9 Hz – 22 kHz
  • Frequency response @ 96 kHz, -0.5 dB: 9 Hz – 45 kHz
  • Frequency response @ 192 kHz, -1 dB: 8 Hz - 75 kHz
  • THD+N: < -100 dB, < 0.001 %
  • Channel separation: > 110 dB
  • Output: 6.3 mm TRS stereo (unbalanced) or mono (balanced) jack
  • Maximum output level at 0 dBFS: +13 dBu (unbalanced), +19 dBu (balanced)



DANTE:

  • 2 x RJ45 for Dante network connectivity (up to 64 channels)



MADI:

  • Coaxial via BNC, 75 Ohm, according to AES10-1991
  • Optical via optional SFP module
  • 62.5/125 and 50/125 compatible
  • Accepts 56 channel and 64 channel mode, plus 96k Frame
  • Single Speed: up to 64 channels 24 bit 48 kHz
  • Double Speed: up to 32 channels 24 bit 96 kHz
  • Quad Speed: up to 16 channels 24 bit 192 kHz



Word Clock:

  • 75 ohm Word Clock BNC connectivity
  • Support 44.1kHz - 192kHz
  • Support full or single speed operation
  • Intelligent Clock Control switches clock source seamlessly



General

  • 2x RJ45 for Dante® network connectivity
    Single Speed: up to 64 channels 24 bit 48 kHz
    Double Speed: up to 32 channels 24 bit 96 kHz
    Quad Speed: up to 16 channels 24 bit 192 kHz
  • MADI input redundancy (requires optional SFP module)
  • Internal routing of up to 268x282 channels
  • 19” enclosure 1 unit height
  • 1,54” full color display with control knob and four buttons for convenient, direct access to all features
  • Remote control via HTTP & JSON
  • internal PSU, optional 12V DC redundant power supply
  • USB 2.0 (for remote control and firmware updates)
  • DC-coupled outputs



Hardware Specifications

  • Dimensions: 440 x 44 x 243 mm (17.3 x 1.7 x 9.6 inches)
  • Weight: 2.8 kg (6.2 lbs)
  • Package: 560 x 315 x 115 mm (22.1 x 12.4 x 4.5 inches)
  • Conformity: CE, FCC, WEEE, RoHS
  • Power supply: internal 30 W 100-240 V AC, external 12 V 2.5 A DC (optional)
  • Power consumption: typ. 20 W, standby 0.5W
