Rolls RM424 - Four Zone Installation Mixer

Special Price $290.00 Regular Price $359.00

discount



SKU
ROLLS-RM424

-Two Microphone Inputs -Three Line-Level RCA Inputs -One Front-Panel 1/8" Input -Four XLR Outputs

Rolls RM424 - Four Zone Installation Mixer

The RM424 Four Zone Mixer from Rolls is ideal for any installation that requires as many as 3 sound sources and a paging mic. It combines a paging microphone input, a combo mic/line input and two line-level source inputs for flexible routing options.

Each input of the RM424 can be switched to any combination of four zone outputs. The outputs are all on balanced XLR connectors. Remote Volume Control inputs provide each zone with the means for external volume control. Additionally, the microphone inputs feature selectable ducking for effective paging. The front-panel speaker and headphone output make pre-assignment monitoring easy, each channel includes a switch to monitor before assigning an output. The RM424's front panel is simple to use, while its back panel provides enough functionality to shine in any four zone environment.

More Information
SKU ROLLS-RM424
Freeshipping Free Shipping
UPC (Universal Product Code) 00675889042405
MPN (manufacturer part number) RM424
Discount INSTANT SAVINGS: 10% OFF
Condition New
Features -Two Mic Inputs with independent switchable phantom power -True 48V phantom power -Two RCA source inputs and one front panel 3.5mm stereo input -Four Balanced XLR Zone Outputs -Remote Volume for each output -Assignable automatic paging
Specs
Inputs
Input Connections 1 x XLR - Mic 1
1 x XLR - Mic 2
2 x RCA phono - Channel 2 (1 x L/R)
4 x RCA phono - Source Inputs (2 x L/R)
1 x 1/8" TRS stereo - Channel 4
Input Impedance XLR Mic: 600Ω balanced
XLR Line: 10kΩ balanced
RCA phono: 10kΩ unbalanced
1/8" TRS: 10kΩ unbalanced
Maximum Input Level Mic: -30 dB
Line: +22 dB
Phantom Power Yes, +48V
Outputs
Output Connections 4 x XLR
Output Impedance 50Ω balanced
Maximum Gain Mic: 60 dB
Line: 30 dB
Headphone Output 1 x 1/4"
Internal Speakers Yes, 1 monitor speaker
Performance
Remote Control Connector 2 x euroblock for remote volume on each output zone
Signal-to-Noise Ratio > 75 dB
THD < 0.3%
IMD < 0.3%
CMRR 60 dB
Frequency Response 20 Hz to 20 kHz
General
Power Adapter 15VDC
Dimensions (W x H x D) 19 x 1.75 x 6.5" (48 x 4.5 x 17 cm)
Weight 7 lb (3 kg)
Producut Video No
