Sennheiser SR IEM G4 -Stereo Transmitter

Features

• Half-rack stereo transmitter in a full-metal housing with OLED display for full control

• Easy and flexible wireless synchronization between transmitter and receiver via infrared

• Compatible with Sennheiser WSM control software for flexible frequency allocation

• Up to 16 compatible channels

• Up to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF range

• Transmission Range: up to 100 meters / 300 feet

• High RF output power (up to 50 mW) depending on country regulations

• Compatible with wireless speaker system LSP 500 PRO

What's in the box?

• SR IEM G4 stereo transmitter
• rod antenna
• power supply
• GA 3 rackmount set
• quick guide
• safety guide
• manufacturer declaration sheet

Technical Data

• Frequency range

  A1: 470 - 516 MHz
  A: 516 - 558 MHz
  AS: 520 - 558 MHz
  GB: 606 - 648 MHz
  G: 566 - 608 MHz
  B: 626 - 668 MHz
  C: 734 - 776 MHz
  D: 780 - 822 MHz
  E: 823 - 865 MHz

• Dimensions

  Approx. 202 x 212 x 43 mm

• Compander

  Sennheiser HDX

• • THD, total harmonic distortion

    <0.9 %

  • Weight

    Approx. 980 g

  • Audio input

    2x XLR-3/¼" (6.3 mm) jack combo socket, electronically balanced

  • Audio output

    ¼" (6.3 mm) stereo jack socket, balanced

  • Signal-to-noise ratio

    >90 dB

  • RF output power

    switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW

  • Switching bandwidth

    up to 42 MHz

  • Peak deviation

    ±48 kHz

  • Nominal deviation

    ±24 kHz

  • Modulation

    Wideband FM stereo (MPX pilot tone)

  • Power supply

    12 V DC

  • Current consumption

    max. 350 mA

  • Max. Input voltage

    +22 dBu

  • Transmission frequency

    Max. 1680 frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 16 factory-preset channels, no intermodulation 6 frequency banks with up to 16 programmable channels

  • AF frequency response

    25 Hz to 15 kHz

  • Temperature Range

    -10 °C to +55 °C

  • Frequency stability

    ±10 ppm

  • Antenna Output

    BNC socket, 50 Ω
